Thimble provides a convenient and efficient means for loop
deadending of steel static wire and bare or insulated
aluminum or copper phase wires. Magnetic induction heating
will occur.
Material:
Body: steel, galvanized
Clevis Pin: galvanized steel
Cotter Pin: stainless steel
| Catalogue Number | Conductor Range mm | Ultimate Body strength KN | Dimension(mm) | ||||
| L | B | W | H | PD | |||
| DH-1 DH-2 | 0-22.23 0-25.40 | 18 27 | 16 16 | 18 18 | 40 | 6 6 | 130 111 |
